How It Works

This guide will show and explain the features which the controller has and how to use them to achieve the best long lasting performance on the track.

Brake

The brake is the most important setting. On the “Hard” setting the car will stop fast, if the brake resistor is turned close to “Soft” the braking effort will be reduced.

Soft Brake adjustment

With brake adjustment switch is possible to add 3,3 ohm resistance when the switch have been set on “Soft”. The 3,3 ohms will be added to normal 3 ohm resistor in total 6,3 ohm.

Anti-brake

The Anti-brake feature helps to get the car through the corner much smoother. Then you use Anti-braketo help the car spin a bit more. Anti-brake has good amplitude ofadjustment.

Resistor

Resistor is the sensitivity or attack of your controller. For greater attack the potentiometer should be adjusted closer to “Fast”.

Traction Control

Traction Control controls the cars middle speed. If the Traction Control has been turned from “Regular” to “Slow” the car becomes much more driveable in the corners.

Choke (electronic)

By adjusting the Choke from “Fast” to “Slow” the output voltage is decreased and the cars maximum speed will drop. If the car goes too fast the Choke can be applied.

NEW

Choke (wire)

Wire Choke controls cars power and smoothness. Choke has a wide range of adjustment from 0 to 42 foot. The choke position is changed using 16 position rotary switch, as well Turbo switch and two positions of electronic choke are integrated. The power circuit is switched using mosfet transistors.

Power

Controller is designed with lowest resistance on full power 0,04 V.
